See part 17 in the diagram
( Grid squares measure 1x1 inch )
Get in touch, we're here to help!
1-866-883-8386
Monday to Saturday
8am - 8pm EST
LATCH W11700916
Fits your 11031312021!
$77.73
In Stock
Fits your 11031312021!
PartSelect Number
PS17217010
Manufacturer Part Number
W11700916
Manufactured by
Whirlpool
Product Description
LATCH Specifications
Keep your top-load washer running safely and smoothly with this replacement lid lock assembly. It’s designed to secure the lid during active cycles, preventing interruptions and ensuring the machine operates only when properly closed. Whether your current latch is worn out or no longer functioning, this component offers a dependable fix. Installation is straightforward, and it fits a variety of washer models, making it a practical choice for restoring peace of mind in your laundry routine.
How Buying OEM Parts Can Save You Time and Money
Troubleshooting
This part fixes the following symptoms:
Locking Issues | Lid or door won’t close | Will Not Start
This part works with the following products:
Washer, Wall Oven, Range.
This part works with the following products:
Whirlpool, Maytag, Kenmore, Kenmore.
Part# W11700916 replaces these:
W11032875, W11394572, W11543566
Customer Repair Stories
Average Repair Rating: 3.9 / 5.0, 1 reviews.
What's this?
- < Prev
- 1
- Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
The lid was closed to hard causing the door strike, lid lock bezel and assembly to break.
Changing the door strike was simple just a quarter turn and it pops off. Changing the assembly, remove the screws from the back side at the top, move to facing the front of the machine pull the top toward you about a half inch and it will open. From the back unplug the correct wire, remove assembly and then install in reverse. Good luck.
Other Parts Used:
-
David from MOUNT CALM, TX
-
Difficulty Level:Easy
-
Total Repair Time:15 - 30 mins
-
Tools:Screw drivers, Socket set
18 of 23 people
found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
- < Prev
- 1
- Next >
Questions and Answers
We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.
- < Prev
- 1
- Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Kaye
June 29, 2024
Do you have this lock lid assembly part #w11032875
For model number WTW5100HW2
Hello Kaye, Thank you for your inquiry. The stock status for parts is always listed above the Add to Cart button on our site underneath the part information. If you are not sure what a stock status means, you can click on it and a separate window will appear with the explanation for what that status means. In the case of this part, it shows as in stock but is not listed as compatible to the model number you provided. The compatible lid lock assembly is part# PS12731130 but it shows as on order from the manufacturer. We hope this helps.
3 people found this helpful.
Was this helpful?
Thank you for voting!
Nathan
November 23, 2025
Washer turns on for a few secs then goes into done. Lid does not secure and can be opened at any time. Checked diagnostics for error and all 4 lights flash on group 1 and group 2. Could the lid switch be the issue?
For model number MVW6200KW3
Hello Nathan, thank you for contacting us. The washer is designed to stop immediately if the lid does not properly lock at the beginning of a cycle. So yes, a faulty lid lock might be causing the issue and needs to be replaced. The part number is PS17217010. Good luck with your repair!
1 person found this helpful.
Was this helpful?
Thank you for voting!
- < Prev
- 1
- Next >
Related Parts
$26.63
In Stock
DOOR STRIKE
$26.63
PartSelect Number: PS16218028
This door strike is a crucial safety component in top-load washing machines, designed to engage with the door latch and keep the lid securely closed during operation. Located along the door frame, it helps prevent water ...
$32.90
In Stock
LID LOCK BEZEL - WHITE
$32.90
PartSelect Number: PS16555327
We've got the perfect solution for your washing machine dilemma - our Lid Lock Bezel in classic white. This tiny, yet crucial, component plays a big role in your Whirlpool washing machine's functionality by securely lock...
$27.28
In Stock
Produce Preserver Filter
$27.28
PartSelect Number: PS3503014
Fresh Flow Produce Preserver is made for your refrigerator to help keep produce fresh for longer by absorbing the chemical, ethylene, that causes your fruits and vegetables to ripen quicker. Your produce could be fresh f...
$25.31
In Stock
Affresh Washing Machine Cleaner - 3 pack
$25.31
PartSelect Number: PS1960673
Having a problem with a funky-smelling washing machine, or one that just doesnt seem to clean your clothes as well as it used to? Say hello to the Affresh Washing Machine Cleaner by Whirlpool. This powerful washing helpe...
$21.95
In Stock
Affresh Dishwasher Cleaner Tablets - 6
$21.95
PartSelect Number: PS12345667
Affresh dishwasher Cleaner is specially formulated to help remove limescale and mineral build-up that can be unsightly and could affect your dishwasher's performance. Each tablet is designed to clean inside your machine ...
$37.89
In Stock
Refrigerator Deodorizer
$37.89
PartSelect Number: PS12739141
Refrigerator deodorizers help to reduce bacteria growth and therefore reduce smells and extend the life of food.
$32.93
In Stock
Cooktop Cleaning Cream
$32.93
PartSelect Number: PS12717774
Make your cooktop shine with Frigidaire ReadyClean Glass and Ceramic Cleaner. Our scratch-free, streak-free formula removes smudges, grease, burnt-on food, dirt and oil, while protecting and polishing to repel dust and d...
$35.68
In Stock
Model Cross Reference
This part works with the following models:
PartSelect Number: PS17217010
Manufacturer Part Number: W11700916
Manufacturer Part Number: W11700916
Brand
Model Number
Description
