Suspension Spring
PartSelect #: PS11738823
Manufacturer #: WP21001598
This suspension spring is used with many washing machines. It is made entirely of metal and is seven inches long.
$11.16
In Stock
Drive Belt - 51 inches long
PartSelect #: PS11738882
Manufacturer #: WP21352320
This V-style drive belt is about 51" long and 3/8" wide. This part is made to slip on the motor pulley to bring the basket up to the speed required and this makes the belt encounter wear and tear.
$13.96
In Stock
Lid Hinge Pin
PartSelect #: PS11741781
Manufacturer #: WP35-2045
This lid hinge pin is just over an inch long. It is all white in color and is made entirely of plastic. Sold individually.
$28.27
In Stock
Lid Hinge
PartSelect #: PS11741780
Manufacturer #: WP35-2044
This lid hinge in an inch and a half long and is used for some washing machines. It is all white in color and it is made entirely of plastic.
$14.21
In Stock
Washer Drain Pump
PartSelect #: PS11741803
Manufacturer #: WP35-6780
This pump helps expel water from the washing machine and is activated after the spin speed is maintained for a specific period of time. NOTE: This is a redesigned part. The pump now mounts on to the b...
$152.70
In Stock
Transmission Pulley and Bearing Kit
PartSelect #: PS2003651
Manufacturer #: 12002213
Also known as Thrust Bearing Kit. This kit includes the pulley, washer, thrust bearing, 2 upper race washers and 1 lower race washer. These parts are NOT available separately - they are ONLY availab...
$88.76
In Stock
Drain Pump with Pulley
PartSelect #: PS11741799
Manufacturer #: WP35-6465
This pump has 2 ports. This pump helps expel water from the washing machine and is activated after the spin speed is maintained for a specific period of time.
$130.28
In Stock
Suspension Springs - Kit of 6
PartSelect #: PS2004049
Manufacturer #: 12002773
This package contains a new set of six springs. The suspension springs in your washer connect to the bottom of tub, and help to hold it in place. If your washer tub shakes, or moves around a lot durin...
$92.78
In Stock
Hose Clamp
PartSelect #: PS11743008
Manufacturer #: WP596669
This hose clamp extends from half an inch to an inch in diameter. It is made entirely of metal and is intended for use with Maytag brand washing machines.
$11.68
In Stock
Screw
PartSelect #: PS11742755
Manufacturer #: WP489483
This screw is sold individually.
$16.63
In Stock
Questions And Answers for PAV2300AWW
We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.
- < Prev
- 1
- 2
- Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Jason
December 30, 2019
Only agitates on one of three cycles
For model number PAV2300AWW
Hello Jason and thank you for writing.
You should try a hard reset first. Go to your breaker box, turn the breaker for your unit off, wait 5 minutes and turn the breaker back on.
If your washer has a selector switch on the control panel, make sure the button for your selection is pressed all the way in, or set properly.
Many washing machines have multiple-speed drive motors. Though it's uncommon, the drive motor may work fine on one speed but not on another. If the drive motor has failed on one speed, you need to replace the entire motor PS11738839. We hope this helps. Please contact us anytime if you require further assistance.
7 people found this helpful.
Was this helpful?
Thank you for voting!
Related Parts:
Gregory
August 17, 2023
Agitator screw keeps coming loose and agitator comes off.
For model number PAV2300AWW
Hi Gregory, thank you for contacting us. If the agitator screw, part number PS11752524, keeps coming loose even after tightening it, then the screw has most probably worn out and it may need to be replaced. Glad to be of help!
1 person found this helpful.
Was this helpful?
Thank you for voting!
Related Parts:
TERRY
November 24, 2023
I BOUGHT A NEW WATER PUMP, SQUEALING NOISE WENT AWAY BUT NOW I HAVE A DEEPER NOISE COMING OUT BUT ONLY ON SPIN CYCLE
EVERYTHING ELSE SEEMS TO WORK FINE WHAT SHOULD I TRY REPLACING NEXT
For model number PAV2300AWW
Hi Terry, thank you for reaching out to PartSelect. Based on our understanding of the issue, we would suggest you replacing the spin bearing, part number PS11741784. We are sure this will help!
Was this helpful?
Thank you for voting!
Related Parts:
Jan
February 15, 2020
The lid switch works, the motor works, the belts are on, but the tub won't spin. I also can not spin it manually. Is this the brake? Which part needs to be replaced?
For model number PAV2300AWW
Hello Jan,
Thank you for your question. Our source suggest replacing the transmission pulley and bearing kit under part PS2003651 for your model to fix the spinning issues. We hope this helps.
Was this helpful?
Thank you for voting!
Related Parts:
David
March 2, 2020
My dcs wall oven doesn't reach nor doesn't hold the temperature on the desired setting when it is in the baking mode! The broil seems to be working fine. But when we use the baking part never reaches to the desired temperature, and also the display never shows the right temperature! Any suggestion? Please and thanks
For model number PAV2300AWW
Hi David,
Thank you for your question. If the oven is not heating correctly, then the issue is likely with the oven sensor, sometimes called the oven thermostat, and you will need to check it with a multi-meter. When testing the sensor with a multi-meter, the sensor should be tested at room temperature and it should be unplugged from the oven. You will need to measure the resistance between the two prongs at the end of the sensor connector. Replace the oven sensor if the reading is less than 900 Ohms or more than 1200 Ohms. If this checks out fine, you will need to check the electronic control board, the bake element and the wiring between these parts to see which once is causing the issue. We hope this helps. Thank you and have a great day.
Was this helpful?
Thank you for voting!
- < Prev
- 1
- 2
- Next >
Common Symptoms of the PAV2300AWW
[Viewing 11 of 11]Leaking
Fixed by
these parts
these parts
Show All
Burning smell
Fixed by
these parts
these parts
Show All
Will not drain
Fixed by
these parts
these parts
Show All
Will not agitate
Fixed by
these parts
these parts
Show All
Spins slowly
Fixed by
these parts
these parts
Show All
Lid or door won’t close
Fixed by
these parts
these parts
Show All
Will Not Start
Fixed by
these parts
these parts
Show All
No hot or cold water
Fixed by
these parts
these parts
Show All
Shaking and Moving
Fixed by
these parts
these parts
Show All
Spinning Issues
Fixed by
these parts
these parts
Show All
Noisy
Fixed by
these parts
these parts
Show All
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
washing machine was making alot of noise
I found the water pump bearings were going bad from humidity. I replaced the pump with a new one and it runs quiet again.
Parts Used:
-
David from Boca Raton, FL
-
Difficulty Level:Easy
-
Total Repair Time:Less than 15 mins
-
Tools:Screw drivers, Wrench set
561 of 572 people
found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
One of the plastic hinge pins brroke
I used a flat screw driver to push in on the releases so I could raise the top of the machine. I then used a torx tool to remove both parts of the hinge, and then used a #2 phillips screw driver, on the new screws I'd also ordered, to re-attach both of the hinge parts. Every thing went just as anticipated.
Parts Used:
-
Allen from North Little Rock, AR
-
Difficulty Level:Really Easy
-
Total Repair Time:15 - 30 mins
-
Tools:Screw drivers
513 of 516 people
found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Pump was making a grinding noise
The pump is located behind a small panel on the back, lower left side of my washer. It's attached to the bottom frame with 3 screws. It has two hoses attached, each with one spring clamp. Lift one side of the washer and slip the drive belt off the pully. Release the spring clamps on the hoses with a pair of pliers and remove the hoses. A small amount of water will drain from the hoses and pump when removed. Remove the three screws holding the pump to the frame and remove the pump. Install the new pump in the same position. Reattach the hoses, replace the belt, and reinstall the cover panel. That's all there is to it.
Parts Used:
-
Ranse from Layton, UT
-
Difficulty Level:Easy
-
Total Repair Time:15 - 30 mins
-
Tools:Nutdriver, Pliers, Socket set
295 of 317 people
