The drum support roller kit (Dryer Repair Kit) allows the dryer to tumble properly by supporting the drum cylinder. The idler pulley provides the tension required for a multi-ribbed belt. The belt att...
This 240V/5400W heating element is strung with a coiled wire made of a nickel and a chrome alloy. This wire receives, but resists, a controlled electric current, causing the wire to heat up. The heat ...
This thermal cut-off kit for a dryer includes one high limit thermostat with a limit of 250 degrees Fahrenheit, and one thermal cut-off fuse (309 degrees). This kit also includes flat heaters with jumper wires.
This dryer drum roller kit is designed to restore smooth and quiet operation in a wide range of dryer models. It includes two drum rollers, four tri-rings, and one to two retaining washers, providing ...
If you notice that your dryer is noisy or will not tumble, you may need to replace the tri ring. This part is triangular, and is less than an inch in size. Tri rings can be found both on the idler pul...
This 18 ml bottle of white appliance touch-up paint is used to cover scratches or marks on your appliance. The white touch-up paint can be used on refrigerators, microwaves, ranges, clothes dryers, an...
This high-limit thermostat with Terminal Extension Arm acts as as safety mechanism that keeps the dryer from overheating. Once the dryer temperature reaches 221 degrees Fahrenheit, this piece will shu...
This manufacturer-certified dryer lint filter is used to collect lint during the dryer cycle, to prevent damage to the machine and to prevent lint from sticking to clothes. This model comes in white a...
If your dryer drum isn’t spinning, the motor might be the issue. This replacement motor works with many Whirlpool-brand dryers made before 1996 and comes with the pulley already attached. It powers th...
$143.77
In Stock
Questions And Answers for AED4475TQ1
Ask our experts a question about this model and we'll get back to you as soon as possible!
19 questions answered by our experts.
< Prev
1
2
3
Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Frank Riha
January 9, 2020
Dryer heats sometimes at high heat setting but doesn't work on other settings. Turn the knob a few times and it may heat. All thermostats were changed so i think it is the timer.Is this very common?
For model number AED4475TQ1
Hello Frank, thank you for your question. Yes, if the unit is not heating all the time, the issue could be with the timer. If the element was tested, and the thermostats were replaced the timer would be the next part we would recommend replacing. I hope this helps.
7 peoplefound this helpful.
Was this helpful?
Thank you for voting!
Sherri
December 31, 2019
My dryer started not shutting off when the door was opened and now will not start.
For model number AED4475TQ1
Hello Sherri,
Thank you for your question. Our sources suggest replacing the dryer door switch for your model under part PS11741701 to fix the issues with the dryer. We hope this helps!
My dryer is not drying clothes well it heats but not real hot could this be a element
For model number AED4475TQ1
Hello Steven,
Thank you for your question. Our sources suggest it is likely the thermal-cut off kit under part PS334299 for your model that would need to be replaced to fix the issues. We hope this helps.
Hi, i put on the thermal cutoff kit #279816 now my dryer wont start
For model number AED4475TQ1
Hello Michelle,
Thank you for your question. Our sources suggest replacing the dryer door switch under part PS11741701 for your model to fix the dryer issues. We hope this helps.
To reach the heating element you only need to open the back cover of the dryer (about 8 nut-head screws). Remember to disconnect the power.
To remove the heating element there are two small nut-head screws. Remove the two electric wires. Then you can pull the heating element away.
You can check the heating element with an ohm-meter or visually inspect it to see if the heating element spiral wire is broken.
Don't hurry to dispose the old element. My model includes a small electric safety part. You'll need to transfer it to the new heating element (that comes without it)..
First tried heating element and thermal fuse with no luck. Ordered thermal cutoff and fixed problem. Had I used an ohm meter first I would have determined problem before having ordered heating element and fuse, as both had resistance. I wast just lazy and ordered the took the most common failed components first before taking dryer back off.
The repair was easy. the most time consuming part was vacuuming the dust from the back of the Dryer, The repair required removing screw from the back panel of the dryer. Then removing screws from the heating element and unplugging the wires. The only moderately diffculy part was swapping the sensor form the old element.
