This 18 ml bottle of white appliance touch-up paint is used to cover scratches or marks on your appliance. The white touch-up paint can be used on refrigerators, microwaves, ranges, clothes dryers, an...
This is a multi-use and multi-appliance screw. It can be used on a microwave, refrigerator, range/oven, air conditioner, dehumidifier, washer, or dryer. The measurements of this screw are 8 x 1/2 inch...
This is a door hinge active with spring, for your range. The hinge controls the opening and closing of the oven door. If your oven door seems to be sticking, you may want to consider replacing this pa...
The light socket on your electric range connects the power source to the light bulb. If your oven light is malfunctioning, you may need to replace the light socket. The light socket is located in the ...
Ask our experts a question about this model and we'll get back to you as soon as possible!
2 questions answered by our experts.
< Prev
1
Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Barbara
March 29, 2023
Are there drip pans available for the gas stove?
For model number WFG525S0HS1
Hello Barbara, thank you for asking. Based on our research, your range does not come with drip pans. You may have to order the complete cooktop, part number PS11775184. We hope this information helps!
front burners not igniting. hear the noise from ignitor
For model number WFG525S0HS1
Hi Dwipal, thank you for getting in touch. First, you may need to make sure the gas feed is not clogged. Try cleaning the burners so that the gas feeds through without interruption. If that is not causing the issue, then you may need to check the spark module, part number PS11755330, as it is most likely faulty. We hope this helps!
I numbered every part. ex: 1 L., for first part removed left side. I used a magic marker to circle the holes and wrote the number of screws used on the part, set the srews in a separete place, so that I new where these screws went to. The cleanup was pretty time consuming, but I was able to keep my stove, when every repairman I called to fix my stove told me I was better off buying a new stove. ($600.00 stove 2 years old)Please Note: The insulation blanket needed for the entire stove is two pieces, the sides and top are one part # and the bottom and back, are another part #. I did not know this. I just purchased the top and sides. I got lucky, the back and bottom were still in good shape. So I guess I should have read the description of the part more carefully to see what it covers, before I ordered it. It took two people two hours to do the work, it was really nice to have an extra set of eyes, to remember what direction pieces of metal from the stove went. I would do it all over in a heart beat instead of buying a new stove.
Replaced igniter and also DSI/direct spark igniter did not fix problem. Called out repairman turned out to be bad gas valve. Replaced that part , now stove works fine.
After reading many forums found that this error happens when trying to clean the oven and there is a failure in the latch motor to lock the oven door. It was suggested 1st to just tunr the breaker off to the over wait and then turn it back on to see if the error would clear by itself. If not then you'll have to do what I did and buy a new Latch Motor and replace it. Fairly easy to do: ) Move oven to get to the back panel ) Disconnect oven from power ) Remove the 8 screws to get the back panel off ) REmove the Latch motor screws (2) and remove the motor after twisting to get the latch rod off ) Put in new latch motor by 1st putting the latch rod in the motor assembly ) Screw the new motor in place ) Replace back panel ) Power on Oven DONE!
