This wheel is a dishwasher rack wheel designed for the upper rack of your appliance. The roller wheel is approximately 1.25 inches in diameters and includes the brushing you need for installation. It ...
This dishwasher water inlet valve is a genuine replacement component engineered to regulate water flow into the appliance, ensuring accurate fill levels for optimal cleaning performance. Constructed t...
This wheel for the lower rack of your dishwasher, it includes the brushing you will need for installation; the axel is not included. You need to line the replacement wheel up with the axel, slide it i...
This dishwasher door gasket creates a watertight seal between the door and the tub, preventing leaks during wash cycles. Made from flexible black rubber, it fits securely along the edge of the door to...
Give your dishwasher handle a secure fit with this silver end cap. It attaches to the side of the handle and keeps everything in place for a polished look. Designed for Bosch and related models, it’s ...
If your dishwasher isn’t draining or cleaning well, this drain pump could be the issue. It helps move water out of the tub during the cycle and fits many Bosch, Thermador, and Gaggenau models. Signs i...
If your dishwasher is leaking or not draining properly, this replacement drain hose might be the fix. It connects the dishwasher to your sink drain or garbage disposal, carrying away dirty water after...
Having trouble with your dishwasher? Let's help you solve that with the Bosch Dishrack Tine Row Holder. This is an original, high-quality part that helps your dishwasher work at full efficiency by sec...
Ask our experts a question about this model and we'll get back to you as soon as possible!
2 questions answered by our experts.
< Prev
1
Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Chuck
November 2, 2021
No water, water line checked no obstructions.
For model number SHX33RF5UC
Hello Chuck, Thank you for the question. This could be caused by a defective Water Inlet Valve. The valve can be tested with a Multimeter. Set your multitester to the R X 1 ohms setting to test for continuity. Place each of the multitester's leads on a terminal. Your multitester should display a reading between 200 and 500 ohms. Closely examine your water inlet valve. The exact ohm resistance rating you should test for may be marked on the valve. We hope this helps!
Hello Curtiss,
Thank you for writing in. Our research has found that part number PS8701614 is the upper rack and part number PS8737395 is the lower rack and both are in stock. We hope this helps.
We let this go for a shameful amount of time before I decided I could probably fix it. The roller broke so you could only pull it out about halfway or it would come off the track. I looked up the part, and bought it. Actually bought two in case it happened again. When I arrived I looked at how it was put together on the other side and then just basically pushed it onto the rod and it was fixed. I am ashamed it took so long to do it. Never be afraid to try it yourself. It was a total of $10 shipped to fix it.
With the help of You Tube, this 50 year old Mom got the job done. Not that complicated if you watch the step by step instructions on the Appliance Pro video. My repairman and husband were both determined to just buy a new one but this 20 year old dishwashing genius was just in need of a little repair. Only need a screwdriver, and slightly confusing as wires hook on a little different on new pumps. I suggest watching video the whole way through and then playing it step by step as you do the repair. Worked great for me. Thanks.
Here are the steps you need to take to do the job properly:
1. turn off electrical circuit breaker to the dishwasher 2. remove 8 total hex screws (3 on each side and 2 at the top) of the inside door panel. The door panel will slide off so be careful and it happens pretty quickly when the last hex screw is removed. 3. unplug the wiring harness to the detergent/rinse aid dispenser 4. you need to use a flat head screw driver to lift the metal flanges on the top and bottom of the detergent/rinse aid dispenser. 5. the unit will pop out toward the inside of the dishwasher 6. insert the new detergent rinse/aid dispenser and very important all metal flanges are pulled back over the plastic edge (top and bottom) of the dispenser unit. The screw driver needs to be used to assist in pushing the dispenser unit as tight to the frame of the door to ensure the metal flanges grab hold and lock in. 7. re-attach the wiring harness 8. re-install the dishwasher door with 8 hex screws. Doing this step alone is challenging as the door frame will want to keep going up to close. I used a small foot stool and placed it inside the dishwasher front area on top of the inside metal door area so the door would stay open roughly half way. I then used my knees to prop up the outer door cover while i got 2 screws started then was able to easily complete the job. 9. run the dishwasher with a detergent packet loaded into your new dispenser. I checked for 15-20 minutes during initially running to insure no issues or leaks. 10. One last note - my Bosch dishwasher had a custom wood door installed to the outer panel to blend in with our kitchen cabinets. The door itself was much heavier as a result. Some of you may not experience the slight difficulty i noted above in step 8. Good luck.
