Also known as a door boot seal.This part is used to keep the clothes inside the tub during the wash cycle. The folds in the bellow allow the tub to move separately from the door during the spin cycle.
This 18 ml bottle of white appliance touch-up paint is used to cover scratches or marks on your appliance. The white touch-up paint can be used on refrigerators, microwaves, ranges, clothes dryers, an...
This is a replacement tub-to-pump hose for your washer. This hose runs from the bottom of the tub to the water pump, and is used to transport water. The hose can develop a hole, and when this happens ...
This water inlet valve attaches the water lines to the back of your appliance. The attaching solenoids on the valve open and close according to the desired temperature or amount of water needed.
This is the replacement bellow clamp for your washer. It is approximately 18 inches in diameter and is sold individually. The bellow clamp goes around the bellow in your washer and holds it in place o...
The door boot spring clamp or outer bellow clamp on your washer is designed to keep the door boot in place. It is circular in shape, and you will find it wrapped around the bellow. To remove the old c...
This hose clamp extends from half an inch to an inch in diameter. It is made entirely of metal and is intended for use with Maytag brand washing machines.
$11.68
In Stock
Questions And Answers for MHWZ400TQ01
Ask our experts a question about this model and we'll get back to you as soon as possible!
5 questions answered by our experts.
< Prev
1
Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Michelle
January 28, 2020
Starts to spin (drains ) but then shuts off with out finishing cycle . Then it tries again but does not complete cycle and shuts down without spinning out ever gets up to hi extraction of spinning
For model number MHWZ400TQ01
Hello and thank you for writing.
It certainly sounds like it could be a faulty or loose drive belt you should check the part(s) for signs of damage and replace it as needed. Please see the part links related to this question just beneath this answer. We hope this helps. Please contact us anytime if you require further assistance.
When put on any cycle, heavy duty, normal, or delicate, the machine does not appear to rinse and spin, the machine will start about shortly after just stops. Clothes inside are still very wet, but there is no water in the machine. If I manually put it on a rinse and spin they come out nice and dry and well spun out. We bought the machine used and now am wondering if this is why they got rid of it :(
For model number MHWZ400TQ01
Hello Heather, Thank you for the question. If you can turn the knob to manually start the rinse and start cycle, this normally indicates the Timer is not advancing on its own. The Timer for this model is sold as part of the Electronic Control Board. If you need help placing an order, customer service is open 7 days a week. Please feel free to give us a call. We look forward to hearing from you!
Door shuts but won’t lock when the start button is pressed.
For model number MHWZ400TQ01
Hello Anne, Thank you for your inquiry. We have researched the model you have provided and we would recommend checking the following parts to fix your issue: Door Lock Latch, the door strike, and the electronic control board. Good luck with your repair.
Hello John, thank you for asking. We have attached a relevant video that may not be exactly the same but will help you in accessing the drum. We hope this helps!
Was this helpful?
Thank you for voting!
Mohammed
February 25, 2024
Stop at rinse. and than move the timer manually it works
For model number MHWZ400TQ01
Hi Mohammed, thank you for getting in touch. Based on the description, the issue is with the control board, part number PS11748533. It processes the cycle settings chosen by the user. You may need to replace the control board to fix the issue. We hope this solves your problem!
Removed the front panel unplugged The washer drained water out, lift the washer up to un screw the drain pump. Then unhooked the hoses from pump put the other pump in.
I discovered water leaking from the bottom of the door on our Kenmore front load washer. I did a little self diagnosis from the internet and found that this seems to be a common problem for front load Kenmore washers and that the ususal suspect is the large rubbery bellows. I examined the bellows on my washer and although I didn't find anything wrong with it, I couldn't find any other likely causes. I shopped around and found PartSelect to be the cheapest for the replacement part. Removal is easy by removing the lower front panel with three small screws on the bottom front, then remove the very top panel and then the top front control panel and finally the door panel. the bellows are actually held in place with a spring loop on the outer and a screw tightener on the inner, both are fairly easy to remove and the bellows comes right off. For installation my best advice is to lube the bellows with a small amount of dishwashing soap in the groove that fits on the washer tub. This will help it slide into place and enables a small amount of sliding fine tuning once it is on. From there it is just a reverse of the removal.
Pump started making noises like ball bearings grinding. took the lower front cover off pulled the strainer out of the pump housing and found $2.55 in nickles dimes and quarters. Some 223 bullets and about 20 bobby pins. Together they had destroyed the impeller, so ordering a new one and installing it did the trick. Easy installation about 15mins.
