GTW725BPN0DG General Electric Washer - Overview
Sections of the GTW725BPN0DG
[Viewing 4 of 4]
Keep searches simple, eg. "belt" or "pump".
LID LOCK SERVICE KIT
PartSelect #: PS17626546
Manufacturer #: WH08X37938
This lid lock, also referred to as a door lock, is a genuine replacement component designed to secure the washing machine lid during operation. It ensures the appliance recognizes when the lid is prop...
No Longer Available
Water Inlet Valve Assembly
PartSelect #: PS12171559
Manufacturer #: WH13X26637
This inlet valve is designed for use in compatible top-load washing machines and plays a key role in regulating water flow during the wash cycle. Controlled by electrical signals, the valve opens and ...
$72.26
Special Order
NUT HUB
PartSelect #: PS8757009
Manufacturer #: WH02X10363
Having trouble with your GE washer? Our Nut Hub could be just the solution you need. This little device has a big job ? it tightly secures your washer hub to the gear case shaft. Its accuracy helps yo...
$19.95
Special Order
Anti-Siphon Clip
PartSelect #: PS271098
Manufacturer #: WH1X2725
This part helps prevent the backflow of water from the tub to main water line.
$13.95
Special Order
Agitator Cap - Short
PartSelect #: PS12073992
Manufacturer #: WH43X25443
Sold individually.
No Longer Available
Hub
PartSelect #: PS8757010
Manufacturer #: WH02X10364
Struggling with a faulty washer? It might just need some love with a simple part replacement. Our GE Washer Hub, often known as the hub nut, could be the perfect fix you need. This tough, reliable lit...
$19.38
Special Order
AGITATOR BASE HYBRID ASSEMBLY
PartSelect #: PS16743416
Manufacturer #: WH43X34257
The agitator rotates back and forth to move the clothes inside the tub to clean the load.
No Longer Available
Questions And Answers for GTW725BPN0DG
We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.
- < Prev
- 1
- 2
- Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Don
November 2, 2021
Will not start. Electricity is hot but machine will not start up.What can i check to find out any parts i'll need to order?
is there any advice or troubleshooting information online?
For model number GTW725BPN0DG
Hello Don, Thank you for your inquiry. We do have symptom based repair advice listed under your model number or through our instant repairman. If your washer will not start, we recommend checking the lid switch assembly, the lid lock harness, the power cord and the control board. We hope this helps.
Was this helpful?
Thank you for voting!
Richard
April 22, 2022
Agitator makes grinding noise ,wont spin
For model number GTW725BPN0DG
Thank you Richard for your question. We have a video that shows potential issues and possible solutions for you to watch. We hope this helps. If you need help placing an order, customer service is open 7 days a week. Please feel free to give us a call. We look forward to hearing from you.
Was this helpful?
Thank you for voting!
Samantha
May 1, 2023
The Agitator doesn’t spin while washing. When nothing is in the machine you can spin it freely. Clothes are not getting washed because they aren’t moving around in the water.
For model number GTW725BPN0DG
Hello Samantha, thank you for reaching out. We have found that the issue is due to the lid lock, part number PS16554755. We hope this helps!
Was this helpful?
Thank you for voting!
S
November 28, 2023
WASHER WILL NOT SPIN
For model number GTW725BPN0DG
Hi thank you for reaching out to PartSelect. If your washing machine detects that its door is open, it will not spin. We would recommend checking the lid switch assembly, part number PS16554755, to get to the root of the problem. Good luck with the repair!
Was this helpful?
Thank you for voting!
David
December 26, 2024
How to remove the agitator.
For model number GTW725BPN0DG
Hello David, thank you for your question. Remove the fabric softener align the raised bump with the opening on the augur. Use the screwdriver to puncture through the inner shaft of the augur. Then twist clockwise until the augur releases and lift it out. This will be difficult be sure to hold the basket from rotating. Unthread the 11 mm bolt lift out the base. To install the new augur, base align the base with the spline shaft and set it into the appliance. Rethread the 11 mm bolt to secure set the augur over the tabs and twist counterclockwise to lock it in place. Align the dispenser to the grooves of the augur and press firmly to secure in. Place and your washer and should be ready to go. We hope this helps.
Was this helpful?
Thank you for voting!
- < Prev
- 1
- 2
- Next >
Common Symptoms of the GTW725BPN0DG
[Viewing 12 of 12]Will not drain
Fixed by
these parts
these parts
Show All
Will not agitate
Fixed by
these parts
these parts
Show All
Leaking
Fixed by
these parts
these parts
Show All
Will Not Start
Fixed by
these parts
these parts
Show All
Lid or door won’t close
Fixed by
these parts
these parts
Show All
Spinning Issues
Fixed by
these parts
these parts
Show All
Locking Issues
Fixed by
these parts
these parts
Show All
Draining Issues
Fixed by
these parts
these parts
Show All
Noisy and Marks Left on Clothes
Fixed by
these parts
these parts
Show All
Water Filling Issues
Fixed by
these parts
these parts
Show All
Shaking and Moving
Fixed by
these parts
these parts
Show All
Cycle Not Advancing
Fixed by
these parts
these parts
Show All
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Washer ran fine but woudl not drain water - low humming noise
Drain all the water out of the tub with a shop vac
Remove rear drain hose and drained rest of water into a bucket
Remove small rear panel (bottom left hand corner) where the drain hose connects
Tipped washer up about 45 degrees to get underneath it - Supported it with a few paint cans
Remove internal drain hose/clamps from pump - w/ pliers
Remove belt cover (gray plastic) with socket - 3 bolts
Remove wire assembly plug from socket
Remove old drain pump with socket - 3 bolts
Install new drain pump - 3 bolts - plug wire assembly into socket
Reinstall belt cover - 3 bolts
Reinstall hose to drain pump (note panel will be inside washer)
Feed drain hose panel through hole and reinstall - 1 nut
Re attached drain hose to exterior drain plug
You are done !
Remove rear drain hose and drained rest of water into a bucket
Remove small rear panel (bottom left hand corner) where the drain hose connects
Tipped washer up about 45 degrees to get underneath it - Supported it with a few paint cans
Remove internal drain hose/clamps from pump - w/ pliers
Remove belt cover (gray plastic) with socket - 3 bolts
Remove wire assembly plug from socket
Remove old drain pump with socket - 3 bolts
Install new drain pump - 3 bolts - plug wire assembly into socket
Reinstall belt cover - 3 bolts
Reinstall hose to drain pump (note panel will be inside washer)
Feed drain hose panel through hole and reinstall - 1 nut
Re attached drain hose to exterior drain plug
You are done !
Parts Used:
-
Mike from NAPLES, FL
-
Difficulty Level:Really Easy
-
Total Repair Time:30 - 60 mins
-
Tools:Nutdriver, Pliers, Screw drivers, Socket set
60 of 86 people
found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Would not drain the water from the tub.
Very simple to repair. Be sure to drain the tub outside or into the sump pump then lay the washer on its side. The pump is right there on the bottom of the basket with 3 bolts. You will also need to remove the belt cover to get to the plug. So simple and saves you hundreds off repair man prices.
Parts Used:
-
Micheal from South Bend, IN
-
Difficulty Level:Very Easy
-
Total Repair Time:Less than 15 mins
-
Tools:Socket set
37 of 56 people
found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Water was dripping into the detergent tray when the unit was off.
Removed the control panel back plate cover. Removed the 3 screws that held the water control valve in place. I then unplugged each solenoid one at a time and plugged it into the new control valve. Once all wires were transferred, I pulled the old valve up and put the new valve on. Then reinstalled the screws that held it down and reinstalled the cover plate. Very simple job !
Parts Used:
-
Richard Bibb from ARLINGTON, TX
-
Difficulty Level:Very Easy
-
Total Repair Time:30 - 60 mins
-
Tools:Nutdriver, Pliers
26 of 33 people
found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
