79573133410 Kenmore Refrigerator - Overview

Sections of the 79573133410

[Viewing 5 of 5]
Keep searches simple, eg. "belt" or "pump".
Refrigerator Front Plate Assembly – Part Number: AGU75188619
Refrigerator Front Plate Assembly
★★★★★
★★★★★
(35)
PartSelect #: PS12374439
Manufacturer #: AGU75188619
If your fridge doors aren’t sealing properly or you’re noticing cold air escaping, this front plate assembly might be the fix. Also called a mullion or flipper, it fits between the French doors to kee...
$200.17
  In Stock
Refrigerator Water Filter LT700P – Part Number: AGF80300702
Refrigerator Water Filter LT700P
★★★★★
★★★★★
(3)
PartSelect #: PS12724833
Manufacturer #: AGF80300702
This refrigerator water filter replacement is for 2010 LG refrigerators that have either forward French doors or are the four-door dispensing models. This filter is designed to minimize impurities tha...
$101.75
  In Stock
Crisper Shelf Glass – Part Number: MHL42613217
Crisper Shelf Glass
★★★★★
★★★★★
(8)
PartSelect #: PS3630671
Manufacturer #: MHL42613217
Having issues with your LG refrigerator's shelving? Our genuine OEM Retractable Glass Shelf is here to help. It's not just an ordinary shelf'this sleek and sturdy glass panel is a practical solution s...
$74.59
  In Stock
Water Inlet Valve Assembly – Part Number: AJU72992601
Water Inlet Valve Assembly
★★★★★
★★★★★
(1)
PartSelect #: PS3533117
Manufacturer #: AJU72992601
This includes the primary and secondary valves along with the wire harness.
$269.48
  In Stock
Refrigerator Door Switch – Part Number: 6600JB1010A
Refrigerator Door Switch
★★★★★
★★★★★
(2)
PartSelect #: PS3529268
Manufacturer #: 6600JB1010A
This door switch is used in refrigerators. It is activated by the closing and opening of the door
$46.23
  In Stock
Evaporator Fan Motor – Part Number: 4681JB1027C
Evaporator Fan Motor
★★★★★
★★★★★
(1)
PartSelect #: PS3523323
Manufacturer #: 4681JB1027C
This 13-volt evaporator fan motor helps circulate air over the refrigerator coils. These coils will then convert the heat into cool air, which is then circulated from the freezer section to the fresh ...
$243.17
  In Stock
Connector,Tube – Part Number: 4932JA3009A
Connector,Tube
PartSelect #: PS3524389
Manufacturer #: 4932JA3009A
$37.76
  On Order
Secondary Water Inlet Valve – Part Number: MJX41869202
Secondary Water Inlet Valve
PartSelect #: PS6448332
Manufacturer #: MJX41869202
This valve helps your fridge deliver water to the ice maker and dispenser. If you’re not getting ice, the dispenser isn’t working, or you hear strange noises, this part might be the fix. It’s easy to ...
$132.70
  In Stock
Refrigerator Door Bin – Part Number: AAP73051302
Refrigerator Door Bin
PartSelect #: PS3613457
Manufacturer #: AAP73051302
This door bin is for refrigerators. Door bin attaches to the inside of the refrigerator door and mostly holds jars and bottles.
$126.16
  In Stock
Temperature Sensor – Part Number: 6500JB2002X
Temperature Sensor
PartSelect #: PS3636270
Manufacturer #: 6500JB2002X
$46.66
  In Stock
Refrigerator Compressor Overload Protector – Part Number: 6750CL0001D
Refrigerator Compressor Overload Protector
PartSelect #: PS3603394
Manufacturer #: 6750CL0001D
The compressor overload protector attaches to the compressor and shuts off the compressor if the compressor motor draws too much current.
$53.89
  In Stock
Door Holder – Part Number: MEG61899901
Door Holder
★★★★★
★★★★★
(1)
PartSelect #: PS3535435
Manufacturer #: MEG61899901
This is a manufacturer-approved refrigerator door closure for your refrigerator. It is made of white plastic and measures approximately 3 inches by 2 inches. If your old closure is damaged, your refri...
$28.96
  In Stock

Questions And Answers for 79573133410

Ask our experts a question about this model and we'll get back to you as soon as possible!

4 questions answered by our experts.
  • 1
Sort by:
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
George
August 13, 2021
Can i replace inner door shelf 12 inches wide x 7.5 inches deep
For model number 79573133410
PartSelect logo
Hello George, Thank you for your inquiry. The larger door basket on the right hand door is part# PS3613457 which measures approximately 12 inches (at the narrowest end) or 14 inches at the widest end, by 8 inches by 5 inches, and the bottom door basket part# PS3613460 which measures approximately 12 inches (at the narrowest end) or 14 inches at the widest end, by 6 inches by 5 inches. Hope this helps.

1 person found this helpful.

Was this helpful?
Thank you for voting!
Related Parts:
Stephen
October 28, 2025
Need plastic wheel for freezer sliding drawer.
For model number 79573133410
PartSelect logo
Hello Stephen, thank you for reaching out. The front rollers for the freezer drawer is part number is part number PS3640036, and the rear rollers are part number PS3640037. We hope this is what you were looking for!

1 person found this helpful.

Was this helpful?
Thank you for voting!
Related Parts:
William
January 17, 2023
There is 2 evaporator fan motors in this freezer but in the part list show’s up only 1 evaporator fan motor So how can I order both?
For model number 79573133410
PartSelect logo
Hi William, thank you for reaching out. The evaporator fan motors, part numbers PS3523323 and PS3523325 are listed as compatible with your given model. If you require assistance to place an order, please contact customer service. We hope that helps!

Was this helpful?
Thank you for voting!
Related Parts:
Jason
December 21, 2023
Sometimes when I open the side by side doors, it trips the breaker outside! Need help!
For model number 79573133410
PartSelect logo
Hi Jason, thank you for contacting us. Based on our understanding, the issue is most probably with the door switch, part number PS3529268. You may need to replace it to fix the issue. We hope that helps!

Was this helpful?
Thank you for voting!
Related Parts:
  • 1

Common Symptoms of the 79573133410

[Viewing 9 of 9]
Light not working
Fixed by
these parts
Fixing
Show All
Door won’t open or close
Fixed by
these parts
Fixing Fixing Fixing
Show All
Leaking
Fixed by
these parts
Fixing Fixing Fixing
Show All
Not dispensing water
Fixed by
these parts
Fixing Fixing
Show All
Door Sweating
Fixed by
these parts
Fixing Fixing
Show All
Noisy
Fixed by
these parts
Fixing
Show All
Fridge too warm
Fixed by
these parts
Fixing
Show All
Ice maker not making ice
Fixed by
these parts
Fixing
Show All
Fridge and Freezer are too warm
Fixed by
these parts
Fixing Fixing
Show All
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
replace leaking water inlet valve assembly
1. Shut off water to refrigerator. 2. Removed bottom sheet metal cover (6 screws). 3. Removed leaking water inlet valve assembly from refrigerator (1 screw). 4. Remove water inlet tube (loosen nut) and tube back to refrigerator (pull from water valve after remove cotter pin washer). 5. Detach two electrical wire harnesses. 6. Install new water inlet valve assembly to refrigerator (1 screw). 7. Replace both water tubes to water inlet assembly. 8. Re-attach both wiring harnesses. 9. Turn water to refrigerator on. 10. Check for leaks. 11. Re-attach bottom sheet cover (6 screws).
Parts Used:
Water Inlet Valve Assembly
  • Richard from JACKSONVILLE, FL
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Screw drivers
40 of 70 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Remove and replace light switch
Video makes it look easy. Kenmore refrigerator does not have "groove" along the right hand side of switch that allows for pushing down on release. Used a thin screwdriver to get under to push while holding switch edge with pliers. Kept slipping. Tape sides to avoid scratching inside of refrigerator.
Parts Used:
Refrigerator Door Switch
  • Debbie from Waltham, MA
  • Difficulty Level:
    A Bit Difficult
  • Total Repair Time:
    30 - 60 mins
  • Tools:
    Pliers, Screw drivers
44 of 85 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
My nephew accidentally forced the door closed last year, which resulted in the door having to be re closed manually folding back the flap. Ugh!
Unscered 2 screws, unplug electrical connection under the screws, slide her flap into grooves, realign screw holes , and rescrew in. Done.
Parts Used:
Refrigerator Front Plate Assembly
  • Tiziana from WARWICK, NY
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    Less than 15 mins
  • Tools:
    Nutdriver
24 of 45 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
