Part Location Diagram of 154325201 Frigidaire Spring Linkage
See part 1A in the diagram
Replacing your Frigidaire Dishwasher Spring Linkage
( Grid squares measure 1x1 inch )
Customer Service Representative

Get in touch, we're here to help!

Monday to Saturday
8am - 9pm EST

customerservice@partselect.ca

Spring Linkage

★★★★★
★★★★★
1 Review
$46.34
  In Stock

Get this part fast! Average delivery time for in-stock parts via standard shipping: 1.8 days.

PartSelect Number PS420766
Manufacturer Part Number 154325201
Manufactured by Frigidaire
Product Description

Spring Linkage Specifications

This linkage attaches to the door spring.
How Buying OEM Parts Can Save You Time and Money

How Buying OEM Parts Can Save You Time and Money

Part Videos

Replacing your Frigidaire Dishwasher Spring Linkage

Replacing your Frigidaire Dishwasher Spring Linkage
Troubleshooting
This part fixes the following symptoms:
Door latch failure | Door won’t close
This part works with the following products:
Dishwasher.
This part works with the following products:
Frigidaire, Kenmore, Crosley, Westinghouse.
Part# 154325201 replaces these:
AP2109352, 419477
Back to Top
Customer Reviews
Average Rating:
★★★★★
★★★★★
1 Review
5.0
Filter By Rating:
  • 5 Stars
    1
  • 4 Stars
    0
  • 3 Stars
    0
  • 2 Stars
    0
  • 1 Star
    0
  • 1
Sort by:
Sorry, we couldn't find any existing reviews that matched. Try using some different or simpler keywords.
  • 1
Customer Repair Stories
 Average Repair Rating: 4.1 / 5.0, 17 reviews. What's this?
  • 1
  • 2
Sort by:
Sorry, we couldn't find any existing installation instruction that matched.
One of the door tension springs and related plastic clip failed causing door to open under full weight
Per the recommendation from PartSelect.com, I purchased 2 new springs and 2 new clips - one set for each side. With the bottom cover plate removed below the door, I removed the remaining spring and clip and installed the 2 new springs and clips by hand. The door now opens with resistance and won't even stay completely opened unless the lower dishwasher tray is rolled out on it. it's like new.
This is the second repair to this dishwasher. Last year I replaced the door latch that had broken with a replacement purchased from partselect.com. That repair was also quite easy.
PartSelect's full part brochures by model made identifying the needed parts simple, and the replacement a breeze.
I even repaired my refrigerator ice maker a couple months ago after purchasing a new control module, and saving both a service fee and the probable full price for a new ice maker.
I've repaired my electric clothes dryer too, and hadn't even thought about all the repairs I'd done thanks to this website, until I told the story of my dishwasher.
I've probably saved $1000 already. Wow!
I love this site.
Other Parts Used:
Door Spring
  • Michael from Redmond, WA
  • Difficulty Level:
    Easy
  • Total Repair Time:
    Less than 15 mins
  • Tools:
    Screw drivers
72 of 77 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
itmes breaking
One Roller detatched and hit the heat coil and melted. Both of the Spring Linkages borke. It's was quite obvious they were made not to last long. My Husband did the repairs. Thank you for asking.
Other Parts Used:
WHEEL & BUSHING ASS
  • Ruth from Portland, OR
  • Difficulty Level:
    Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Screw drivers
63 of 125 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Dishwasher door practically fell open
All I had to do was replace the spring and retainer on the side of the dishwasher which amounted to pulling it out far enough to reach the eyelet that the hook went into and then stretching it to the retainer attached on the other end. I really like partselect, I have done some things in the past and they are very helpful on the site and on the phone and I would recommend them to anyone and I would not normally do that unless it has been an excellent experience.
Other Parts Used:
Door Spring
  • Daniel from Fremont, NE
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    Less than 15 mins
52 of 58 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Door would drop when opened....no tension on springs
First unplug the unit.

Second remove the kickplate. When you do this pay attention to the position of the insulation panel. It is confusing as to how it is put back together. Simple if you see how it comes apart.

Third unsrew the screws that hold dishwasher in palce under the counter top.

Genly pull the appliance from under the counter top. Understand the copper piping connected to the unit for water will only allow you to pull it out a few inches. Otherwise you would have to turn off and disconnect the water supply.

Reinstall the plastic clipsand springs. There are several holes in the frame of the dishwasher where the springs will attach. The further back you attach them, the more tension will be applied to the springs. This part of the operation is somewhat trying as you have limited visibility and access.

When springs and clips are installed, test door, slide unit back in place, reattach kickplate and insulation panel and then reattach to countertop.

All in all relatively simple and doable. If I had any problem it wasnot paying attention to how the insulation panel and kickplate came apart. No big deal.
Other Parts Used:
Door Spring
  • Richard from Voluntown, CT
  • Difficulty Level:
    Easy
  • Total Repair Time:
    30 - 60 mins
  • Tools:
    Screw drivers
33 of 35 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
With an explosive bang, the spring on one side of the dishwasher door broke. The door weighed like a million pounds and was difficult to open and close.
I found the parts needed on Part Select and read comments by users. I took the suggestion to buy both springs at the same time and the door linkages too. Although they were pricey, the parts arrived in a few days and were absolutely perfect. To my suprise and delight, the entire fix for the broken spring and link and the opposite spring and link were easily accomplished in less than 10 minutes. The links just hook directly onto a small hook on the door and the springs have specially bent ends that fid the linkage and then the adjustable length holes on the door. It made me feel quite manly for about fifteen minutes as I made everyone in the house open and close the dishwasher door several times.
Other Parts Used:
Door Spring
  • Steve from Memphis, TN
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    Less than 15 mins
19 of 20 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Door spring had broken; door would fall open
Removed the bottom panel on the unit (2 screws hold it on) and pulled the dishwasher out about 4"--after turning off electricity to the unit. Removed the broken spring and the old linkage and replaced them with the new parts. Pushed the diswasher back into place, and replaced the bottom panel. Turned on the electricity and the diswasher door is "good as new." This is quite simple to do; just takes patience.
Other Parts Used:
Door Spring
  • Sue from Weymouth, MA
  • Difficulty Level:
    Easy
  • Total Repair Time:
    30 - 60 mins
  • Tools:
    Screw drivers
16 of 16 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Spring broke on dishwasher
After having a repairman out to changing the door handle and seeing how easy it was...I decided to try to fix the spring issue myself. I am fairly confident with most small fix it items in our house, so decided to order the original spring & linkage. The website was pretty self-explanatory, but wished someone hinted that when you have one broken spring, the other usually goes out within a short period of time. Note to others, ordered 2 springs & linkage and avoided another shipping charge. Do both springs at the same time, and will save you time in the long run. Otherwise, super easy to change out...wish all appliance issues were this easy to fix. I did not need to take of door off....I just needed to lay on floor & become a little limber. Other than that...super easy.
Other Parts Used:
Door Spring
  • Michelle from West Linn, OR
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    15 - 30 mins
10 of 10 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Both springs and links on door broken.
Previous self-repair instructions provided on this site were very helpful. I started by removing items from under the sink and inspecting drainage and water hoses of the dishwasher to determine amount of "play" for sliding the washer out. Next, remove the two screws that secure the washer under the top of the counter. Then, remove the kickplate and barrier at the bottom. The washer then slid easily out far enough to explose the spring connector arms. I removed the old springs from the floor and the pieces of the old links (one link was ok, but I saved it for a spare). I installed the links and springs on both sides and connected to the first hole. By the way, the hole in the lower frame relatively close behind link is NOT the spring connection hole. There are a series of holes farther back. After testing the door and re-hooking the springs twice,I decided that the fourth hole gave the tension that I wanted. Now the door will come up about half way on its own, but will stay fully open when pulling out the empty bottom basket. Slide the washer back under the counter, being careful not to catch the insulation at the top and sides of the washer. Line up the top screw holes and install the screws. Install the barrier panel and kickplate at the bottom. I had to "fiddle" with the kick plate and barrier panel a little to get it right because I did not play close attention when removing them. I probably saved $100 by doing it myself. My wife said "It's just like new!"
Other Parts Used:
Door Spring
  • Harry from Magnolia, AR
  • Difficulty Level:
    Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Screw drivers
9 of 11 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Installed springs, linkage, gasket, and bracket
Repair was easy. Unfortunately I really didn't need the springs or linkage, but I couldn't see that until I took the dishwasher out from the counter. The springs were not stiff enough to keep the door from just falling open. So I cut about an inch off the long end and bent it into a hook. I didn't need new linkages the old ones were fine. The gasket made the biggest difference and went in very easy. The door will be difficult to close for a few times then everything works great.
Other Parts Used:
Dishwasher Tub Gasket - Gray Door Spring Lower Rack Bracket
  • Mark from West Linn, OR
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    30 - 60 mins
  • Tools:
    Pliers, Screw drivers
9 of 11 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Leak in hose, door leakage, weak door springs.
I received the parts 3 working days from order. They were in perfect condition and exactly like the originals.
Pulled dishwasher out from under counter. Removed door. Replaced drain hose. Replaced gasket. Replaced springs. Put door back on. Tried rinse cycle. Placed dishwasher back under counter. Works like new.
Other Parts Used:
Dishwasher Tub Gasket - Gray Door Spring Drain Hose
  • Ronald from Berwick, PA
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    30 - 60 mins
  • Tools:
    Pliers, Screw drivers
9 of 21 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
  • 1
  • 2
Questions and Answers

We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.

1 question answered by our experts.
  • 1
Sort by:
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Linda
November 21, 2019
Difficulty getting door to latch
For model number FFBD2406NB11B
PartSelect logo
Hello Linda, Thank you for contacting us. I have researched the model you have provided and have found the part you are looking for is PartSelect Number: PS12585635. Hope this helps!

1 person found this helpful.

Was this helpful?
Thank you for voting!
Related Parts:
  • 1
Related Parts
Model Cross Reference
This part works with the following models:
PartSelect Number: PS420766
Manufacturer Part Number: 154325201
Brand
Model Number
