This dryer repair kit consists of five commonly replaced dryer parts: one multi-rib belt (part #661570V and measures 93 1/2 inches long), four drum support rollers, one idler assembly, nine tri-rings,...
This Idler Pulley includes the tri-ring and gasket and everything included here is manufacturer-certified. This part maintains correct tension on the drive belt in order to spin the drum properly. If ...
When connected to electricity the dryer heating element glows red hot and generates heat. When air is blown over it, it heats the air which is used to dry the clothes. The heating element fits inside ...
This drum support roller is sold individually. Most dryers require two. The tri-rings are included. This is a drum support roller for a dryer. It is a genuine replacement part. The part includes the d...
The Drive Belt is a 93 1/2" belt which wraps around the dryer drum to allow tension and movement. If broken the dryer will not turn properly, or there may be loud noises. The part is rated as "medium"...
This thermostat may differ in appearance, but functions the same as the original part. This part controls the temperature of the inside of the dryer drum and prevents the dryer from overheating.
If you notice that your dryer is noisy or will not tumble, you may need to replace the tri ring. This part is triangular, and is less than an inch in size. Tri rings can be found both on the idler pul...
Also known as Thermal Cut-Off kit. The thermostat acts as a safety mechanism that keeps the dryer from overheating and the fuse is like a backup system - it's set to trip at a higher temperature than...
$67.94
In Stock
Questions And Answers for WED8300SW2
Ask our experts a question about this model and we'll get back to you as soon as possible!
7 questions answered by our experts.
< Prev
1
2
Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Lakisha
November 8, 2021
I’m receiving a f01 error message. Please help.
For model number WED8300SW2
Hello Lakisha, thank you for your question. Our research indicates that an F01 error code could be resolved with a simple reset, by unplugging the dryer for 1 minute and then plugging it back in. If this does not resolve the issue, your thermostats and fuses will need to be inspected for continuity. If these parts are in working condition, then your main control board may need to be replaced. We hope this helps!
Hello Carol, thank you for your question. The whirlpool Cabrio dryer F01 error means the main control has an internal failure. That part is PartSelect Number: PS11748354. I hope this helps.
2 people found this helpful.
Was this helpful?
Thank you for voting!
BYRON
February 9, 2023
I BOUGHT A USED WHIRLPOOL DUET SPORT DRYER THAT WAS MISSING THE START BUTTON. WE WERE ABLE TO STILL GET IT TO WORK BY PRESSING A BLACK CONTACT BUTTON THAT WAS ON THE BOARD. THAT HAS COME OFF AND I NEED A REPLACEMENT. THE BOARD IS STILL GOOD I THINK-SUGGESTIONS>?
For model number WED8300SW2
Hello Byron, thank you for the question. The start button you are looking for is not sold separately, you will need to order the User Interface Assembly for it, the part number is PS11746631. We hope this sorts out your problem!
The only setting i can use is the timed drying that will run a complete cycle. On the auto selections timer will not keep accurate time ,it jumps ahead .
For model number WED8300SW2
Hello Duane, Thank you for your inquiry. We have researched the model you have provided and we would recommend checking the following parts to fix your issue: the moisture sensor, the thermal fuse, the cycling thermostat, and the user interface board with timer switch. Check the board for any visible damage or loose connections, and you can test the other parts with a multimeter. Also check for any restrictions to the vent and lint filter duct. We hope this helps and if you need help placing an order, customer service is open 7 days a week. Please feel free to give us a call. We look forward to hearing from you!
When I press start button the sensing light comes on and Dryer does not start?
For model number WED8300SW2
Hello Betty, thank you for your inquiry. We suggest you take a close look at Door Switch and Actuator Kit, part number PS334284, to check whether it is working properly. Good luck with the repair!
First I unplugged the dryer, then removed the back panel, this exposed most all of the wiring and I could see the heater coils. Not knowing what the problem was I started looking at the coils and could not see any broken parts. So then checked the thermal fuse for continuity I removed the two wires from it with a small pair of needle nose pliers, it was held in place by two screws, once they were removed the fuse came out easily, I checked continuity with a volt meter placing the meter on X1 Ohms and could not get a reading. I replaced with a new one and put it all back together the way I took it apart. Then I plugged it in and it worked first time, I now have warm dry clothes.
Cleaning the lint out of the whole machine took quite a bit of time--it was everywhere. Underneath the lint trap was a collection that ultimately ruined the thermal fuse where it restricted the air flow considerably.
Ascertaining the problem was the most time consuming part.
The actual repair was quite simple and didn't take but 15-20 minutes.
Received your parts, Popped them both right into place, Even though only one side needed to be replaced, I wanted them to match up. It was amazing how easy this was. My husband was quite impressed I had ordered these rather then look for either a new or used dryer from some other source.
