The point of the lid switch is for the tub to stop spinning when the washer lid is opened. It is a safety precaution just in case someone decides to stick their hand inside the washer while the tub is spinning.
This drive hub kit (part number W10528947VP) is for washers.
Drive hub kit W10528947VP connects the spin basket to the spin shaft that spins the basket. The kit may include multiple parts; refer to...
This is a replacement clutch assembly or cam kit for your washer. The clutch assembly is mounted on the drive shaft on the bottom of your washer. You may need to replace the clutch assembly if the spl...
These parts are the replacement suspension rod supports for your washer. They are made of plastic and are approximately 1 ½ inches in diameter. This package will come with an 8-piece set of suspension...
This is the replacement cold water inlet valve for your washer. It is mainly blue in color and has two solenoids. The water inlet valve in your washer connects to the water source and solenoid wires, ...
The drain hose carries used water from the washer to your house drain.
$31.80
In Stock
Questions And Answers for MVWX655DW0
Ask our experts a question about this model and we'll get back to you as soon as possible!
24 questions answered by our experts.
< Prev
1
2
3
Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Lisa
July 7, 2021
My drum and agitator spin in opposite directions and make a loud grinding noise. Do you know what is causing this?
For model number MVWX655DW0
Hello Lisa, Thank you for the question. We suggest checking the Washer Drive Pulley for wear or damage. We hope this helps!
I have replaced these parts in this order.Gear clutch
hub
washer plate
shift actuator.
i have run a diagnostic multiple times and the code that comes up is f7 e0
meaning that it displays the f rinse spin done, e nothing.
i am at a loss
For model number MVWX655DW0
Hello Don, thank you for your question. The Washer F7E0 error code means the main board has lost power or the voltage being supplied is too low. If you have reset the unit, and replaced the above mentioned parts, the most likely issue is the main board which is PartSelect Number: PS10062118. I hope this helps!
2 people found this helpful.
Was this helpful?
Thank you for voting!
Gregory
February 17, 2020
Washer is stuck on drain and won't do anything else?
For model number MVWX655DW0
Hello and thank you for writing.
Your washer DRAIN HOSE is causing a siphoning condition. Your washing machine drain hose is pushed way too far into the standpipe in the wall. This creates a vacuum or siphoning effect and the water is pulled out of the washer as it fills with water. We hope this helps. Please contact us anytime if you require further assistance.
1 person found this helpful.
Was this helpful?
Thank you for voting!
Donald
December 28, 2022
When spins like it is out balance make’s grinding noise
For model number MVWX655DW0
Hello Donald, thank you for contacting us. Please inspect the drive belt, part number PS11747978, for wear and tear. Also, check the suspension, part number PS12347546, and the drive pulley, part number PS10057144. These are the most probable culprits of the issue. Customer service is available 7 days a week if you require assistance placing an order. Thanks again for reaching out!
Hello washer lid locked and fills up but then it won’t agitate and won’t spin out to get water out of it just sits in door lock mode and in wash cycle mode . Possible solution for this problem would be greatly appreciated
For model number MVWX655DW0
Hello Robert, Thank you for your inquiry. Researching the model number that you have provided, we would recommend checking the drive motor, the capacitor, the actuator, the gearcase, the drive pulley, the drive belt and the drive hub kit. Check the pulley, belt and hub kit for any visible damage and you can test the other parts with a multimeter. If you are unfamiliar with how a multimeter functions, we have videos available to assist you. Good luck with your repair.
The instructions that came with the part were worthless. Essentially, unplug, put in new part, plug it back in. I spent a considerable amount of time on the internet and finally found a video showing how to open the top. Unlike other models, it is held down by clamps in the back rather than clips in the front. Once finding this information the installation was simple. Remove the clamps and the back of the console, slide the top forward and lift, remove and replace the lock and reassemble. You don't even have to remove the hoses.
Well, first investigated and found loose nut on drive clutch. First take off the two screws with nut drive then cover off using a screwdriver blade to snap off the cover. Then socket ratchet to take off the nut on drive clutch. take off belt by slowly rotating the drive gear. two screws that hold the electronics to the upper drive clutch and put aside, so you can snap off the cover for drive clutch on upper part with screwdriver and off the parts come and install whole unit back as took it apart. Line up the new upper clutch so that is position as was before. (Using parts diagram helps a lot as www. partsselect.com has for you or Maytag.com.) Then put the electronic part board back on and the gear and nut. Make sure it is tight by several attempts to make sure it's snugged up good and then slowly roll belt back on the pulley and motor drive. Put your cover guard back on with two screws and done.
