The door strike on your washing machine allows your washer door to lock properly, and operate efficiently. If you notice that your washer door will not open or close, leaks or the washer will not star...
This door lock and switch assembly is manufactured to lock the door on your front load washer to prevent it from opening while it is running. You may need to replace the door lock and switch if the do...
The pump is what your washer uses to remove the water from the tub. This part is the pump and motor assembly which includes the red flapper to prevent drain back flow.
Also known as a Door Boot Seal and is used in front load washers. This part is used to keep the clothes inside the tub during the wash cycle. The folds in the bellow allow the tub to move separately f...
This is a replacement screw for your washer or dryer. The screw is approximately half an inch in length and is a Phillips-head screw. It screws in from the outside of the drum, into the vane/baffle. T...
Ask our experts a question about this model and we'll get back to you as soon as possible!
12 questions answered by our experts.
< Prev
1
2
3
Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Hugo
December 15, 2019
How can i remove the seal to get into the door interlock?
For model number FAFW3801LW3
Hello Hugo, thank you for your question. We have an installation video for the door lock assembly at the following link.
https://www.partselect.com/PS12364048-Frigidaire-131763256-Front-Load-Washer-Door-Lock-and-Switch-Assembly.htm?SourceCode=4&SearchTerm=FAFW3801LW3&ModelNum=FAFW3801LW3
I hope this helps!
2 people found this helpful.
Was this helpful?
Thank you for voting!
Sylvia
January 12, 2020
I replace the door lock because the panel said lock. And that was only one of problem.. i think... now will not wash with clothes in it....it wants to start to wash and then it stops. and if you leave it on without clothes in it then it will wash and then it will stop... please help
For model number FAFW3801LW3
Good Day Sylvia. Thank you for your question in regards to your unit (Model Number FAFW3801LW3). Based on our research, you may need to replace one or more of the following parts in order to solve the issue that you are having: 1) Door Strike (PartSelect Number PS890617). 2) Door Hinge with Bushings (PartSelect Number PS1152380). 3) Drain Pump (PartSelect Number PS7783938). You can order this part either online at our website www.PartSelect.com or by calling us by phone at 888-260-4310. Best Regards.
Hello Donna, Thank you for writing. There can be a few things to investigate. Door Lock and Switch PartSelect Number PS12364048, Inlet Water Dispenser Valve PartSelect Number PS1145692, and PartSelect Number PS1990814.
Hi Emma,
Thank you for your question. There are 2 shock absorbers in your washer. This shock absorber can be used for either the left or right side. If you would like to place an order for it, you may order it either online or by calling our customer service line and anyone will be happy to assist you. We hope this helps! If you have any questions, please let us know.
I need to replace the laundry product dispenser drawer but don't have a part number and the site isn't showing me my particular part. Is there a part number for the drawer?
For model number FAFW3801LW3
Hello, Thank you for contacting us. We have researched the model you have provided and have found the part you are looking for is PartSelect Number PS1145699. If you need help placing an order, customer service is open 7 days a week. Please feel free to give us a call. We look forward to hearing from you!
This was one of the simpliest repairs I have ever done taking less than 5 minutes to complete. On the inner door I removed the two screws that hold the plastic catch in place. I then removed the broken catch and put the new catch in place. Finally I replaced the two screws that hold the catch in place and it was done.
1. Unplug unit. 2. Unscrew 2 nuts holding top in place in rear of unit using phillips head screwdriver. 3.Slide top back and remove. 4. Open door of washer and unscrew 2 screws holding in door lock unit. 5.Pull out unit from the top and install new unit reconnecting the 3 wire connections.
remove top of machine by removing 3 screws along the top edge in the back of your machine and then sliding the top back and up. Then loosen the screws holding on the control panel enough to get to the 2 screws at the top of the door panel. Next remove bottom panel by removing 2 screws along bottom edge then pulling it free from snaps. Then along the outside lip of the bellow, just inside the door, is a wire clip that is easily removed by prying it past rubber lip with a screw driver and lifting it away. Remove the door panel by removing the 2 screws you exposed by loosening the control panel and 2 more along the bottom that were exposed when removing bottom panel. After the door panel is removed and the bellow is completely exposed, you will find that it is held in place by a circular spring which wraps the whole way around the drum opening. Again it can be removed by prying it out away from the groove in which it sits with a screw driver. Now your machine is broken down as far as it needs to be. From here you can follow the directions included in your new bellow kit and put it back together by following these instructions in reverse.
