See part 616D in the diagram
( Grid squares measure 1x1 inch )

Get in touch, we're here to help!

Open until 12am EST

customerservice@partselect.ca

Plastic Tube

$22.35   In Stock

Get this part fast! Average delivery time for in-stock parts via standard shipping: 1.8 days.

PartSelect Number PS3526625
Manufacturer Part Number 5210JA3005E
Manufactured by LG
Product Description

Plastic Tube Specifications

This part is the replacement water line or tube for your refrigerator. It is made of white plastic and is sold individually. This tube supplies water to the ice maker and water dispenser If your refrigerator is leaking, or it will not dispense water or ice, you may have a damaged water line. When you replace the water line, you may want to pick up a new water tube union as well. You can use a utility knife to cut the old water line where it is damaged and use the union to attach the new water line to the old one. This tubing is an OEM part from the manufacturer.
How Buying OEM Parts Can Save You Time and Money play video

How Buying OEM Parts Can Save You Time and Money

Troubleshooting
This part fixes the following symptoms:
Leaking
This part works with the following products:
Refrigerator, Freezer.
This part works with the following products:
LG, Kenmore.
Part# 5210JA3005E replaces these:
AP4445608, 5210JA3005G, 5210JA3005M, 5210JA3005Q
Questions and Answers

Ask our experts a question about this part and we'll get back to you as soon as possible!

4 questions answered by our experts.
Sort by:
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Orlando
October 30, 2019
Is this a 5/16 od line?
For model number 79577543600
Hello Orlando, thank you for your question. This part is 1/4 Inch O.D. plastic tube. 92" long. I hope this helps!

6 people found this helpful.

Was this helpful?
Thank you for voting!
Dave
September 27, 2021
HOW CAN I REPLACE THE PLASTIC HOSE THAT RUNS THRU THE DOOR TO THE WATER DISPENSER. TWO SE[ARATE TECHS CAME TO THE HOUSE BOTH TOLD ME THAT IT CANT BE DONE THE PLASTIC HOSE IS STUCK IN THE INSULATION.$245 LATER THEY BOTH SAID I NEED A NEW DOOR! HELP!!!!!!
For model number LRSC26923TT
Hello Dave, thank you for your question. We have a video on how to change the water line. It is not your model refrigerator but should be the same idea. We hope this helps. Good luck with your repair!
play video

4 people found this helpful.

Was this helpful?
Thank you for voting!
Sally
November 22, 2019
We need to replace both plastic tubes that feed into the refridgerator water filter. I know one part is mju62070603, but i can't read the number on the other part. Can you advise asap?
For model number LG AP5253550
Hello Sally, thank you for writing. We will be happy to look into this, but we will need the model number for your refrigerator to do so. Here is a link to some tips on our website for locating the model number: https://www.partselect.com/Find-Your-Refrigerator-Model-Number.aspx. We look forward to hearing back from you!

Was this helpful?
Thank you for voting!
Jane
January 5, 2022
I just ordered this tube. Want to be certain it is the right size. I need to replace the water line tube on the back of the fridge. It is white & smaller than what is at the Home Depot. All the tubes were the same size & I was told they are all the same for water lines. I don't understand why. Just a regular fridge.
For model number LFX25960SB
Hello Jane, Thank you for contacting us. We have researched the model you have provided and have found the part you are looking for is PartSelect Number PS3536013. If you need help placing an order, customer service is open 7 days a week. Please feel free to give us a call. We look forward to hearing from you!

Was this helpful?
Thank you for voting!
Related Parts:
Customer Repair Stories
 Average Repair Rating: 4.0 / 5.0, 2 reviews. What's this?
Sort by:
Sorry, we couldn't find any existing installation instruction that matched.
Broken water line
Remove water filter and water filter holder. Removed cover on back of frig. Removed clip where water line connects to back of water filter. Took half inch wrench pushed in on water line lock to release line. Repeat at other end. Reverse steps to put on new line. Easy repair.
Other Parts Used:
Plastic Tube - 5/16 Inch
  • Debbie from FISHER, AR
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Screw drivers
47 of 58 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Water leaking from back of the refrigerator
Pretty simple fix.

1) Removed the screws from lower back plate
2) Removed the screws holding the plastic water lines in place (little plastic brackets - several of them)
3) Take a picture of how the tubing and what hose goes into what part - the 5/16" hose can go into 2 different spots - I didn't do this and I had to fix this
4) Pull out the hose "tabs" that lock the clamp into place (several)
5) Push in new hose
6) Put in clamp
7) I had to remove the filter on the inside of the fridge. Remove the filter, there is one screw that comes out, then you will have access to the hose clamps
8) Repeat for all the other hoses
9) Put the plate and brackets back into place (the picture really helps on how to orient and route the 3 different tubes
10) Test the water
11) Crack open a beer for a job well done

Super easy - take a picture! It will save you time!
Other Parts Used:
Plastic Tube - 5/16 Inch
  • Jason from PLEASANT HILL, CA
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    30 - 60 mins
  • Tools:
    Pliers, Screw drivers
7 of 9 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Related Parts
Model Cross Reference
This part works with the following models:
PartSelect Number: PS3526625
Manufacturer Part Number: 5210JA3005E
Brand
Model Number
Description
LG
71013
Refrigerator
LG
78412
Refrigerator - Refrigerator
Kenmore
79531002700
Refrigerator
Kenmore
79531006700
Refrigerator
Kenmore
79539113600
Refrigerator
Kenmore
79558812900
Refrigerator
Kenmore
79558813900
Refrigerator
Kenmore
79558814900
Refrigerator
Kenmore
79558816900
Refrigerator
Kenmore
79558819900
Refrigerator
Kenmore
79558822900
Refrigerator
Kenmore
79558823900
Refrigerator
Kenmore
79558826900
Refrigerator
Kenmore
79558829900
Refrigerator
Kenmore
79571012010
Freezer
Kenmore
79571012011
Freezer
Kenmore
79571012012
Freezer
Kenmore
79571013010
Freezer
Kenmore
79571013011
Freezer
Kenmore
79571013012
Freezer
Kenmore
79571014010
Freezer
Kenmore
79571014011
Freezer
Kenmore
79571014012
Freezer
Kenmore
79571016010
Freezer
Kenmore
79571016011
Freezer
Kenmore
79571016012
Freezer
Kenmore
79571019010
Freezer
Kenmore
79571019011
Freezer
Kenmore
79571019012
Freezer
Kenmore
79571022010
Freezer
