Part Location Diagram of WP9724509 Whirlpool Lid Bumper
See part 4 in the diagram
Replacing your Kenmore Washer Lid Bumper
( Grid squares measure 1x1 inch )
Customer Service Representative

Get in touch, we're here to help!

Monday to Saturday
8am - 9pm EST

customerservice@partselect.ca

Lid Bumper

$10.11
  In Stock

Get this part fast! Average delivery time for in-stock parts via standard shipping: 1.8 days.

PartSelect Number PS11747040
Manufacturer Part Number WP9724509
Manufactured by Whirlpool
Product Description

Lid Bumper Specifications

This gray and white washer lid bumper contains a rubber bottom and is sold individually.
How Buying OEM Parts Can Save You Time and Money

How Buying OEM Parts Can Save You Time and Money

Part Videos

Replacing your Kenmore Washer Lid Bumper

Replacing your Kenmore Washer Lid Bumper
Troubleshooting
This part works with the following products:
Washer, Washer Dryer Combo.
This part works with the following products:
Kenmore, Whirlpool, Maytag, Roper.
Part# WP9724509 replaces these:
285639, 354241, 354241D, 501536, 93770, 93770D, 9724509, 9724509D
Back to Top
Customer Repair Stories
 Average Repair Rating: 3.1 / 5.0, 4 reviews. What's this?
  • 1
Sort by:
Sorry, we couldn't find any existing installation instruction that matched.
Washer would not run, lid switch broken
Repair was easy. Removed two side panels on the control plate. Removed two phillips screws that hold the control panel to the body of the washer. Disconnected the electic connection to the wires leading to the lid switch. Three sided of the lower cover lift over and removed from the washer frame. Access to the lid switch and wire retainers was easy. Removed two screws holding the remaining parts of the switch and replaced with new. Re-routed the wires through the retainers. Set the sides back on making sure the set all the way back in the frame and fit properly into the plastic strips on the back of the washer. Reconnected wires, screws and end caps.
Other Parts Used:
Lid Switch Assembly Bumper Lid Switch Actuator Assembly
  • Nicola from Centreville, MD
  • Difficulty Level:
    Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Pliers, Screw drivers
762 of 800 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Top part of agitator (auger) was not turning
Using kit 285587 was straight forward. Removed fabric softener dispenser & sealing cap. It took more time to find the socket set (needed a 7/16 socket) with a long driver (10 inch) than to unscrew & remove the auger & agitator.
Cleaned up the bowl whilst it was apart (good buildup of junk under the agitator). Replaced agitator, new thrust washer to find that grease should be applied but isn't included in kit (get part not 350849). Grrr.... Applied new auger, cam, dogs and holder. (No instructions in kit for assembling cam, dogs & holder, but you can work it out ok). Applied new bolt & washer, new seal on cap. Installed fabric softener. Could have been a 15 minute job but peace and quiet in the garage makes it worthy of taking longer ;-)
Other Parts Used:
Seal, Inner Cap Agitator Bolt Lid Hinge Mounting Screw Upper Agitator Agitator Repair Kit
  • Michael from Claremont, CA
  • Difficulty Level:
    Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Pliers, Socket set
175 of 201 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
water leak
I stripped the machine down and replaced the tub seal and drain hose.
Other Parts Used:
Drain Hose with Clamp
  • Mark from Farmer City, IL
  • Difficulty Level:
    A Bit Difficult
  • Total Repair Time:
    More than 2 hours
  • Tools:
    Nutdriver, Pliers, Screw drivers, Socket set, Wrench (Adjustable), Wrench set
22 of 233 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
broken timer knob and lid bumper
the timer knob shaft must be held in place from spinning while the knob hub is removed, simply grasp the shaft with needle nose pliers below whats left of the hub and with another pair of pliers grasp what is left of the knob hub and rotate counter clockwise, once it is broken free it should spin right off. Reverse this process to install the new timer knob.
Installing the lid bumper is simple just pull out the old bumper with needle nose pliers and start the new bumper in from the bottom of the lid and work bumper until the bumper clears the hole in the lid, you may need a small flat screwdriver to work it in gently as not damage the finnish or the bumper when you clear the thicker part of the bumper flange it will lock right into the lid.
Other Parts Used:
Timer Knob
  • ken from central point, OR
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    Less than 15 mins
  • Tools:
    Pliers, Screw drivers
1 of 3 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
  • 1
Questions and Answers

We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.

4 questions answered by our experts.
  • 1
Sort by:
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Brian
July 29, 2019
Why does my washer make so much noise during the spin cycle? When spinning it sounds like the drum is hitting against the cabinet. Also, when I move the drum by hand it seems loose to me. I checked the insides and everything seems to be where it belongs. Any solutions?
For model number MVWC416FW0
PartSelect logo
Hi Brian, Thank you for your question. If the drum is sounds like it is banging against the cabinet during the spin cycle and it seems loose when you turn it by hand, the issue could be the drive belt. It is either loose, not positioned correctly on the pulley or it is worn out. You should also also check the pulley to see if it is worn or loose as well. I hope this helps. Thank you and have a great day!

2 people found this helpful.

Was this helpful?
Thank you for voting!
Robert
October 31, 2019
Washer fills and drains but no spin. Belt on and tight. What other part options do I have for to be cause. Regards Robert
For model number ITW4671EW0
PartSelect logo
Hello Robert, Thank you for the question. I suggest testing the Washing Machine Door Lock Assembly PartSelect Number PS12704713. If defective it may not pick up the lid is closed and preventing it from spinning. Hope this helps!

1 person found this helpful.

Was this helpful?
Thank you for voting!
Lawrence
November 4, 2019
It is extremely noisy when going into the spin cycle after a wash or a rinse. The washer is so noisy, that I have to wear hearing protection when entering the laundry room.
For model number 110.20222510
PartSelect logo
Hi Lawrence, Thank you for your question. If the washer is noisy going into the spin cycle, you may have to check the suspension rods to see if they worn or damaged. If they are, you will need to replace them. I hope this helps. Thank you and have a great day!

1 person found this helpful.

Was this helpful?
Thank you for voting!
Jack
October 31, 2019
Washer makes a lot of noise when its in thespin cycle
For model number RTW4641BQ1
PartSelect logo
Hello Jack, thank you for writing. This is likely due to either a faulty Washer Drive Pulley, part number PS10057144, or Drive Block, part number PS11741977 for your washer. Good luck with your repair!

Was this helpful?
Thank you for voting!
  • 1
Related Parts
Model Cross Reference
This part works with the following models:
PartSelect Number: PS11747040
Manufacturer Part Number: WP9724509
Brand
Model Number
Description
Kenmore
1066695120
Refrigerator
Kenmore
106695120
Refrigerator
Kenmore
106695121
Refrigerator
Kenmore
1067935010
Refrigerator
Kenmore
10682872600
Washer - Kenmore Washing Machine Model 106.82872600 (10682872600, 106 82872600) Parts
Kenmore
11010202001
Washer
Kenmore
1101050299
Washer - Kenmore Washing Machine Model 110.1050299 (1101050299, 110 1050299) Parts
Kenmore
11010502990
Washer
Kenmore
11010502991
Washer
Kenmore
11010852990
Washer
Kenmore
11010852991
Washer
Kenmore
11012202100
Washer
Kenmore
11012502100
Washer
Kenmore
11012852100
Washer
Kenmore
11013202200
Washer
Kenmore
11013212200
Washer
Kenmore
11014102300
Washer
Kenmore
11014112300
Washer
Kenmore
11014202300
Washer
Kenmore
11014212200
Washer
Kenmore
11014222300
Washer
Kenmore
11014502300
Washer
Kenmore
11014852300
Washer
Kenmore
11015732400
Washer
Kenmore
11015842400
Washer - Kenmore Washing Machine
Kenmore
11015852400
Washer
Kenmore
11015862400
Washer
Kenmore
11015864400
Washer
Kenmore
11016101690
Washer
Kenmore
11016101691
Washer
