Models
>
FGHD2433KF1
FGHD2433KF1 Frigidaire Dishwasher - Overview
Sections of the FGHD2433KF1
[Viewing 7 of 7]
Manuals & Care Guides for FGHD2433KF1
Click to downloadInstall
Installation Instructions
(1.45MB)
Manual
Owner's Manuals
(7.80MB)
Manual
Owner's Manuals
(7.80MB)
Wiring
Wiring Diagram
(0.31MB)
Keep searches simple, eg. "belt" or "pump".
Dishwasher Tub Gasket - Gray
PartSelect #: PS8260227
Manufacturer #: 154827601
This grey OEM dishwasher tub gasket is a 73" grey rubber part that creates a seal around the dishwasher to prevent any water leakage during a cycle. If it's damaged or broken, you'll start seeing wate...
$34.76
In Stock
Water Inlet Valve - 120V 60Hz
PartSelect #: PS1990907
Manufacturer #: 154637401
This water inlet valve is usually located behind the lower kickplate panel in either the right or left corner. The attaching solenoids on the valve open and close according to the desired amount of water needed.
$43.89
In Stock
Upper Spray Arm
PartSelect #: PS11770483
Manufacturer #: 5304506516
The upper spray arm helps distribute water from the top of the dishwasher tub.This spray arm is a genuine OEM replacement part for your dishwasher. This spray arm is for the upper part of your dishwas...
$45.82
In Stock
Silverware Basket
PartSelect #: PS17219661
Manufacturer #: 5304535382
This is a basket for washing flatware or silverware in your dishwasher.
$46.21
In Stock
WHEEL & BUSHING ASS
PartSelect #: PS16745479
Manufacturer #: 5304532229
The single rack roller kit comes with one axle/clip and one wheel/roller. The rack wheel is designed to allow the rack of your dishwasher to roll in and out. If the rack will not complete this task, o...
$8.75
In Stock
Splash Shield Kit
PartSelect #: PS2203346
Manufacturer #: 154701001
This is installed at the bottom corners of the door seal.
$24.46
In Stock
Heating Element Brass Nut
PartSelect #: PS1524878
Manufacturer #: 154106202
This nut is sold individually. It is used to install the heating element.
$10.32
In Stock
Latch
PartSelect #: PS16218716
Manufacturer #: 5304525218
This door latch with the switches is a simple on/off mechanism that prohibits the dishwasher from operating when the door is open.
$57.78
In Stock
Dishwasher Drain Hose
PartSelect #: PS9494138
Manufacturer #: 807117001
The drain hose connects to the pump located below the lower spray arm. It aids in proper dishwasher drainage. Size: 7.5 feet long
$42.18
In Stock
Questions And Answers for FGHD2433KF1
We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.
- < Prev
- 1
- 2
- 3
- Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Chuck
October 8, 2021
Dish washer starts then stops with pf indicator
For model number FGHD2433KF1
Hello Chuck, Thank you for the question. The Power Failure Error code can indicate a interruption in power. You can try to reset the appliance by disconnecting power at the breaker for a few mins and restarting. You can also try to Press the "Start/Cancel" button to clear the "PF" error code. We hope this helps!
4 people found this helpful.
Was this helpful?
Thank you for voting!
Susan
January 11, 2020
I am getting the message "er" on my Frigidaire dishwasher. What does it mean? How can I fix it?
For model number FGHD2433KF1
Hi Susan. This is a keypad error you can try to power-cycle the dishwasher. However if this does not work you will have to replace the keypad. Thank you for your question and good luck with your repair!
1 person found this helpful.
Was this helpful?
Thank you for voting!
Related Parts:
Control Panel with Touchpad - Black
$452.72
Special Order
Bruno
October 27, 2023
Heating element on all the time and overheating, I already changed the thermostat and didn’t do anything still overheating, I have to unplug to turn it off
For model number FGHD2433KF1
Hello Bruno, thank you for getting in touch. We would recommend replacing the control board, part number PS12365809, to fix the issue. We hope this helps!
1 person found this helpful.
Was this helpful?
Thank you for voting!
Related Parts:
Electronic Control Board
$211.29
In Stock
Steve
January 6, 2024
My Frigidaire dishwasher door opens lower (more than level) and I think the spring or cable may be broken? What do you think?
M# FGHD2433KF1
S# TH94647585
How many do I need?
What are the part numbers for each?
Can you determine the manufacture date of this machine?
For model number FGHD2433KF1
Hello Steve, Thank you for your inquiry. We recommend checking the hinges-which come as a kit, door springs-most models require two and cable friction cables-most models require two. Based on your model and serial number, we show that this model was made in November of 2009. Good luck with your repair.
1 person found this helpful.
Was this helpful?
Thank you for voting!
Related Parts:
Chip
November 15, 2024
Does this model have a filter ?
For model number FGHD2433KF1
Hello Chip, thank you for your question. Yes, the Filter is PS975892. There is also a Filter Base PS11770494. Good luck with your repair.
1 person found this helpful.
Was this helpful?
Thank you for voting!
Related Parts:
F-FILTER Assembly
$273.05
Special Order
Filter Base
$28.05
In Stock
- < Prev
- 1
- 2
- 3
- Next >
Common Symptoms of the FGHD2433KF1
[Viewing 10 of 10]Leaking
Fixed by
these parts
these parts
Show All
Not cleaning dishes properly
Fixed by
these parts
these parts
Show All
Will not fill with water
Fixed by
these parts
these parts
Show All
Not draining
Fixed by
these parts
these parts
Show All
Door latch failure
Fixed by
these parts
these parts
Show All
Will Not Start
Fixed by
these parts
these parts
Show All
Not drying dishes properly
Fixed by
these parts
these parts
Show All
Noisy
Fixed by
these parts
these parts
Show All
Door won’t close
Fixed by
these parts
these parts
Show All
Will not dispense detergent
Fixed by
these parts
these parts
Show All
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
The spray arm would fall off during the washing cycle.
Repair was simple. I unscrewed the old grommet which held the old spray arm and screwed-on the new one. About 30 seconds was required. Other people having this problem should note that the spray-arm is made of three pieces which are inseparable when the arm is new. The arm is sold in this form. However, when your machine is having the problem that the arm falls off, the three pieces become separate. When you want to replace the spray arm, only one new part needs to be ordered because this part encompases all three components.
Parts Used:
-
Roy from Worcester, MA
-
Difficulty Level:Really Easy
-
Total Repair Time:Less than 15 mins
824 of 841 people
found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Water leaking from Inlet Valve
Remove the bottom cover plate. Disconnect the water inlet and black rubber hose. Remove 2 mounting screws. Pull out electrical connector. Reverse order. Be sure to get the brass inlet connector really tight so it won't leak. I did the final tightning after the part is mounted. Not a bad repair at all. The only problem was that it leaked in the first place and messed up my subfloor and laminate flooring.
Parts Used:
-
CHRIS from ROANOKE, VA
-
Difficulty Level:Easy
-
Total Repair Time:30 - 60 mins
-
Tools:Nutdriver, Pliers, Screw drivers, Socket set, Wrench set
621 of 636 people
found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Lower Rack Roller Missing
Took the roller out of the package, snapped it into place. Less than 15 seconds. Works good as new.
Parts Used:
-
Sandra from Mount Vernon, WA
-
Difficulty Level:Really Easy
-
Total Repair Time:Less than 15 mins
377 of 385 people
found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
